Toyota Yaris: Third generation (XP130; 2010–present)

Third generation (XP130; 2010–present)

Third generation (XP130; 2010–present)

For North America, the XP130 series was released in the fourth quarter of 2011 as a 2012 model under the Toyota Yaris name. Offered in both three- and five-door hatchback styles, Toyota Yaris offers only the 1.5-liter engine with a five-speed manual or optional four-speed automatic transmission. The 2012 model year North American Yaris three- and five-door hatchbacks are available in the base L (CE in Canada), mid-range LE and sport-tuned SE trim levels.
